Milwaukee Electric Tool Corporation
13135 West Lisbon Road
Brookfield, Wisconsin 53005
TEL: (800) 729-3878
25
1 Sheave Housing
1/2 Ton 1
1 & 2 Ton 1
2 Gear Housing (Includes Oil Seals)
1/2 Ton 1
1 & 2 Ton 1
3 Gear Box Cover 1
(Includes Oil Seals)
4 Spring Washer 1
5 O-Ring 1
6 Pressure Relief Fitting 1
7 Dowel Pin 2
8 Gear Case Gasket 1
9 Oil Fill Plug 1
10 Oil Drain Plug 1
11 Oil Level Check Plug 1
12 Oil Seal 1
13 Screw 4
14 Motor Coupling 1
15 Oil Seal 2
16 Bearing 2
17 Input Pinion 1
18 Retaining Ring 3
19 Brake Adapter 1
20 Bearing 2
21 High Speed Gear 1
22 Intermediate Pinion
1/2 Ton 1
1 & 2 Ton 1
23 Bearing 2
24 Output Pinion 1
25 Overload Clutch Assembly
1/2 Ton 1
1 & 2 Ton 1
26 Retaining Ring 2
27 Bearing 2
28 Load Sheave Shaft Assembly 1
(See Figure 20)
29 Load Sheave 1
(See Figure 20)
30 Spacer 1
(See Figure 20)
31 Oil Seal 1
32 Output Gear
1/2 Ton 1
1 & 2 Ton 1
* SAE 90 EP Gear Oil 1½ pt
Ref.
No. Description Qty
Parts List for Transmission Parts
* Not Shown
