FUNCTIONAL DESCRIPTION
11
5
1. Wood work surface
2. Bumper
3. Cabinet corner
extrusion
4. Rigid caster
5. Tool organizer
6. Drawer slide
3
2
4
6
7. Swivel caster with
brake
8. Charger mounts
9. Cord storage brackets
10. Power strip
11. Grommet
12. Side handle
8
9
1
12
7
10
SYMBOLOGY
Warning
Read Operator's Manual
Electrical Shock Hazard
Do not open more than one drawer at a
time. Bench may tip, causing injury.
Lock wheels when bench is not being
moved. Unlocked wheels can allow the
bench to move unexpectedly.
Do not use drawers as steps. Bench
may tip, causing injury.
FPO
Lock all drawers before moving the bench.
Do not step on side shelf. Shelf may
collapse or break. Bench may tip, causing
injury.
ASSEMBLY
CAUTION
Be sure to follow the assembly in-
structions for the appropriate
bench. Do not use power tools to assemble
bench. Tighten bolts with hand wrenches.
Tools Required
Phillips
screwdriver
Safety
glasses
10 mm
Wrench
13 mm
Wrench
Hardware Included
NOTE: Items not shown to actual size.
Hardware Item Description Quantity
AA
Bolt M6 x 16L 4
BB
Screw M4 x 12L 8
CC
Screw M4 x 16L 12
NOTE: Begin product assembly close to the nal
intended location of your bench. This product is
heavy and may be dicult to move after assembly.
Item Description Quantity
Side handle 1
Front Bumper 4
Rear Bumper 2
Cord storage bracket 2
Cabinet corner
extrusion
2
