Milesight Network Camera User Manual | 5 - System Operation Guide | 124
Parameters Function Introduction
Device-profile
Usually you can use the default settings without configuring Profiles Settings. If you
need to customize some profiles settings, you can click the Edit button to make
further settings and click save button, it will list the Device-profiles you created.
Please refer to the meaning of the options as follows:
[Name]: Customize the profile name.
[Max TXPower]:Enter the maximum transmit power. The TXPower indicates power
levels relative to the Max EIRP level of the end-device. 0 means using the max EIRP.
EIRP refers to the Equivalent Isotropically Radiated Power. The Max TXPower must
be between 0~16.
[Join Type]: OTAA and ABP are optional, the default option is OTAA.
• OTAA: Over-the-Air Activation.
For over-the-air activation, end-devices must follow a join procedure prior to
participating in data exchanges with the network server. An end-device has to
go through a new join procedure every time as it has lost the session context
information.
• ABP: Activation by Personalization.
Under certain circumstances, end-devices can be activated by
personalization. Activation by personalization directly ties an end-device to a specific
network bypassing the join request - join accept procedure.
[Class Type]: Device type is Class A by default. Users can check the box of Class B
or Class C to add the class type.
[MAC Version]: Choose the version of the LoRaWAN® supported by the end-
device. 1.0.0/1.0.1/1.0.2/1.1.0 are optional, the default option is 1.0.2.
[Regional Parameters Revision]: Revision of the Regional Parameters document is
supported by the end-device.A and B are optional, the default option is B.
[RX1 Data Rate Offset]: The offset used for calculating the RX1
data-rate is based on the uplink data-rate.
