Installation
*INSTALLATION*
59
The water protection system
The Miele water protection system pro-
tects all parts of the washing machine
from water damage.
The system consists of three main com-
ponents:
- the inlet hose
- the electronic unit and drainage and
overflow protection
- the drain hose
Inlet hose
- Protection against bursting
The inlet hose is tested to withstand
pressure of at least 7,000kPa.
Electronic module and housing
- Floor tray: any leaking water from the
washing machine is collected in the
floor tray. There is a float switch to
close the water intake valve. The wa-
ter inlet is shut off and any water in-
side the suds container is drained
away.
- Leak protection: any leaking water that
is not collected in the floor tray is de-
tected. The water inlet is shut off and
any water inside the suds container is
drained away.
- Overflow protection: this prevents the
washing machine from taking in too
much water and overflowing. If the
water level exceeds a certain level, the
drain pump switches on and pumps
the excess water away.
Drain hose
The drain hose is protected by a ventila-
tion system which prevents the washing
machine from being emptied com-
pletely.
Connection to the water supply
Health risk and risk of damage
due to contaminated incoming water.
The quality of the incoming water
must correspond to the drinking wa-
ter specification of the country in
which the washing machine is being
operated.
Always connect the washing machine
to the mains water supply.
The water connection pressure needs to
be between 100 and 1000kPa. If the
water connection pressure exceeds
1000kPa, a pressure reducing valve
must be installed.
A stopcock with a ¾inch threaded
union is required for the connection. If
this is not available, only a qualified in-
staller may connect the washing ma-
chine to the mains water supply.
The washing machine is not suitable
for connection to a hot water supply.
The washing machine must not be
connected to a hot water supply.
Connecting the water inlet hose
Screw the water inlet hose onto the
thread of the water inlet with the nut.
Slowly open the stopcock and check
the connection for leaks.
Correct the position of the seal and
screw thread if necessary.
