42” 6-Burner Gas Cooktop
KM 3484
KM 3484
Page 2 of 5
SPECIFICATIONS
KM 3484 G - Item# 26348450USA
KM 3484 LP - Item# 26348451USA
Unit Width 42
1
/2” (1079 mm)
Unit Height (To Gas Connection) 3
1
/4” (83 mm)
Unit Depth 21
5
/16” (542 mm)
Niche
Cut-Out Dimensions 41
1
/2” (1054 mm) W x 20
3
/8” (518 mm) D
Minimum Back Spacing From Wall 2
3
/4” (70 mm)
Minimum Countertop Thickness
13
/16” (20 mm)
Minimum Recommended distance to
ventilation hood
30” (760 mm)
Gas Burners
Normal Burner (2) 9,000 BTU (G/LP)
Fast Burner (2) 12,000 BTU (G/LP)
Wok Burner (Left) (1) 15,300 BTU (G/LP)
Wok Burner (Right) (1) 16,500 BTU (G/LP)
Total Maximum BTU Output 73,800 BTU (G/LP)
Gas
Gas Connection 1/2” NPT
Maximum Gas Supply Pressure
Natural Gas - 14” WC (34.9 mb),
1
/2 psi (3.5 kPa)
LP Gas - 14” WC (34.9 mb),
1
/2 psi (3.5 kPa)
Minimum Gas Supply Pressure
Natural Gas - 6” WC (15 mb)
LP Gas - 10” WC (25 mb)
Electrical
Electrical Requirements 120 V, 60 Hz, 15 A
Power Cord NEMA 5-15P, 4 ft (1.2 m)
Shipping
Shipping Weight 75 lbs (34 kg)
Shipping Dimensions 45
11
/16” W x 7
7
/8” H x 23
5
/8” D
Support
Call 800.843.7231
Miele Website
8www.mieleusa.com
20/20 Link
82020technologies.com
Specification Sheets TRS 10112016
KM 3484
Features:
• 6 completely sealed burners:
(1) 16,500 BTU Double inset super
burner
(1) 15,300 BTU Double inset super
burner
(2) 12,000 BTU Super burners
(2) 9,000 BTU High-speed burners
• Side control panel
• Stainless steel knobs
• Fast ignition system
• Ignition safety control
• Wok ring included
