Installation
*INSTALLATION*
94
Water drainage
The appliance drainage system has a
non-return valve, which prevents dirty
water from flowing back into the dish-
washer via the drain hose.
The dishwasher is supplied with approx.
5ft (1.5m) of flexible drain hose with an
internal diameter of 7/8" (22mm).
The hose can be extended using a con-
nection piece to attach a further length
of hose. The drainage length must not
be longer than 13ft (4m) and the deliv-
ery head no higher than 3ft (1m).
If the hose is to be directly connected to
the drainage outlet on site, use the sup-
plied hose clip (see the installation dia-
gram).
The hose can be directed to the left or
the right of the appliance.
The on-site connector for the drain hose
can be used for various hose diameters.
If the connector extends too far into the
drain hose, it must be shortened. Other-
wise, the drain hose can become
clogged.
Only use a Miele approved connection
piece when extending the drain line.
Only use a Miele extension drain hose.
The drain hose must not be shortened.
Lay the drain hose so that it does not
kink and is not being subjected to
pressure or tugged.
Risk of damage from leaking wa-
ter.
Leaking water can cause damage.
After servicing the appliance, ensure
that the drain does not leak.
Venting the water drain
If the on-site drainage connection is sit-
uated lower than the guide path for the
lower basket rollers in the open door,
the drainage system must be vented.
Otherwise, a siphoning effect during a
program can cause the wash cabinet to
empty itself of water.
Open the dishwasher door fully.
1
2
Remove the lower basket.
Insert a screwdriver into the middle
opening of the vent valve in the left
wash cabinet wall.
Press the screwdriver further into the
opening and push it through the
membrane behind.
The vent opening for the water drain is
now open.
