Umbau- und Montageanweisung
M.-Nr. 11313351 17 von 50
Diese Unterlagen dürfen ohne unsere Genehmigung weder vervielfältigt noch Dritten zugänglich gemacht werden. Eigentumsrechte vorbehalten. 12.05.2021
A Βιδώστε το μπροστινό τοίχωμα με 4βίδεςM4x25, βλέπε εικ.7.
el
en-US
APCL 15/30 stand installation instructions
Reason: Installing a washer or dryer on a stand enables a more ergonomic height to be achieved.
Parts included
Quantity Mat. no. Designation
1 Stand
2 Tensioning strip
4 B6.4 washer
2 M6 x 30 bolt
4 M6 nut
4 S12 plug
4 8.4 washer
4 8 x 65 wood screw
8 15 x 44 x 3 washer
8 Spacer
2 Clamping plate
4 CEM 6 x 12 raised-head screw
2 M6 x 20 bolt
1 Front panel (closed stand only)
2 Side panel (closed stand only)
12 M4 x 25 raised-head screw (closed stand only)
Danger due to incorrect service work
WARNING
Danger due to incorrect service work.
There is a risk of serious damage, injury, or even death if service work is carried out incorrectly.
A Service work may only be carried out by a qualified service technician with specialist training, knowledge and
experience.
A All applicable safety guidelines must be followed.
A Wear personal protective equipment.
A Read the Miele service documentation before starting service work.
Measures to be carried out before starting any service work
- Carry out appropriate electrical safety checks.
- Disconnect all machine utility connections in accordance with the operating instructions.
Measures to be carried out after service work has been completed
- Carry out appropriate electrical safety checks.
- Check the appliance for correct operation.
