Je bekijkt pagina 33 van 48
31
Fig.5-3
① ③ ⑤②
7 8 6
Any pressing of button is eective only
under button and display unlocked state.
When the machine is disinfected，press
this button to cancel it. then the will
be extinguished.
No. Icon Description
1
2
Default HYBRID mode
Switch to E-heater mode
Switch to ECONOMY mode
Switch to VACATION mode
Adjust vacation days (1-360 days)
Switch to HYBRID mode
Use this key to switch mode
Icon will light up. then the unit will
heat up water to 60
°C
at least for
disinfection.
Click the button to turn on the forced sterilization
function.
NOTE: When the operating
conditions are not met to turn on
this function, the corresponding
icon on the wire controller lights
up briefly and then goes out.
16
17
18
When any key is invalid, this icon will flash 3 sec.
The icon lights up when the water temperature is
being set.
The icon lights up when the clock is being set.
20
When the heat pump is operating and producing hot
water, the icon lights up.
21
When the SG signal is invalid, this icon does not light
up and the machine does not switch on normally.
（some units）
19
Wireless:
will be lightened when Wireless is connected;
will be extinguished when Wireless is not
connected;
will flash with 2Hz frequency when setting
Wireless.
HEAT PUMP ICON:
Smart Grid ICON:
HYBRID MODE:
Operating in heat pump mode, the electric heater and
heat pump will heat up together when in extremely low
ambient temperatures or when the heat pump has been
running for a long time without reaching the set Temp.
High temp. Alarm
If water temp is higher than 50
°C
, it will be lightened,
otherwise it will be extinguished.
10
11
12
13
Error:
It will be lightened
when unit is under protection/error
.
VACATION MODE:
For the outgoing vacation mode, the water tank is set
at 15°C. Maintains low tank water temperature,
preheats hot water and anti-freeze lines, while
reducing on/off operation of the tank.
14
15
E-HEATER MODE:
Operate in accordance with the heat pump mode, the
heat pump outdoor unit and the electric heater running
at the same time.
ECONOMY MODE:
In accordance with the heat pump mode of operation,
the heat pump external unit heats up to the maximum
water temperature before turning on the electric
auxiliary heater for heating, the heat pump and the
electric auxiliary heater will not be turned on at the
same time.
It is recommended to use this mode of operation when
making hot water alone, which is more energy-saving.
