The hose must be of sucient length and diameter such that it will extend to at
least 3 m beyond the outside of the building
The venting should only take place on the certainty that the refrigerant will not get
blown back into any adjacent buildings, and that it will not migrate to a location
below ground level.
The hose is made of material that is compatible for use with HC refrigerants and oil
A device is used to raise the hose discharge at least 1 m above ground level and so
that the discharge is pointed in an upwards direction (to assist with dilution).
The end of the hose can now discharge and disperse the flammable fumes into the
ambient air.
There should not be any restriction or sharp bends within the vent-line which will
hinder the ease of flow.
There must be no sources of ignition near the hose discharge.
The hose should be regularly checked to ensure that there are no holes or kinks in
it, that could lead to leakage or blocking of the passage of flow.
When flammable refrigerant are employed, appliance shall be stored in a well
-ventilated area where the room size corresponds to the room area as specifiec
for operation. For specific information of the refrigerant amount and the unit
model, please refer to the nameplate on the unit itself. Please refer to the cooling
capacity on the nameplate of the machine you purchased to match it with the
corresponding minimum room area model listed below.
Appliance shall be installed, operated and stored in a room with a floor area
larger than:
<=2.6kW units: 17.33m
>2.6kW and <=3.5kW units: 25.4m
>3.5kW and <=5.2kW units: 34.67m
>5.3kW and <=7.1kW units: 47.33m
Reusable mechanical connectors and flared joints are not allowed indoors.
•
•
•
•
•
•
•
•
•
•
•
•
When carrying out the venting, the flow of refrigerant should be metered using
manifold gauges to a low flow rate, so as to ensure the refrigerant is well diluted.
Once the refrigerant has ceased flowing, if possible, the system should be
flushed out with OFN; if not, then the system should be pressurised with OFN
and the venting procedure carried out two or more times, to ensure that there is
minimal HC refrigerant remaining inside the system.
20. Transportation, marking and storage for units
1. Transport of equipment containing flammable refrigerants
Compliance with the transport regulations
2. Marking of equipment using signs
Compliance with local regulations
3. Disposal of equipment using flammable refrigerants
Compliance with national regulations
4. Storage of equipment/appliances
The storage of the appliance should be in accordance with the applicable regulations
or instructions, whichever is more stringent.
5. Storage of packed (unsold) equipment
Storage package protection should be constructed such that mechanical damage to
the equipment inside the package will not cause a leak of the refrigerant charge.
The maximum number of pieces of equipment permitted to be stored together will
be determined by local regulations.
Note for the minium room area when using flammable refrigerant
NOTE
11
