10
Hood Mounting Screw Installation:
1 Determine and mark the centerline on the wall where the hood will be installed.
2 Select a mounting height between a minimum of 25.6'' and a suggested maximum of
29.53'' above the range to the bottom of the hood. Mark a reference line on the wall.
3 Tape template in place, aligning the template centerline and bottom of template with
hood bottom line and with the centerline marked on the wall.
D
13.38"
7.48"
15.35"
3.14"
6.3"
Centerline of cabinets
and/or cooktop
Mark the hole
location with in
0.375" to 0.5" of
the ceiling or the
upper most hole
location.
Overlap the
holes when
install the
adjustable
decorative
chimney.
Tape
Wall bracket
25.6'' min to cooking surface
29.53'' max to cooking surface
NOTE: Ensure that horizontal lines are level prior to marking hole locations.
