Midea R410A T3 Top-discharge Split Type Series 50Hz MCAC-UTSM-201501
13
Model
MHB-76HRN1
MHB-76CRN1
Type
High static pressure duct
Power supply
\
220-240V~, 1Ph, 50Hz
Cooling
Capacity (T1/T3)
Btu/h
75,100/64,100
75,100/64,100
W
22,000/18,800
22,000/18,800
Input (T1/T3)
W
7,500/8,850
7,500/8,850
EER (T1)
W/W
2.93
2.93
Heating
Capacity
Btu/h
85,000
\
W
25,000
\
Input
W
8,300
\
COP
W/W
3.01
\
Rated input (Whole units)
W
11,700
11,700
Rated current (Whole units)
A
19.3
19.3
Indoor air flow
m
3
/h
4,250
4,250
Indoor standard ESP (External static pressure)
Pa
196
196
Indoor noise level
dB(A)
58
58
Refrigerant type
\
R410A
R410A
Refrigerant control
\
Capillary
Fan
Type
\
Centrifugal fan
Centrifugal fan
Motor model (×Quantity)
\
YDK300-4X(×2)
YDK300-4X(×2)
Input (Hi/med/lo)
W
690/580/500
690/580/500
Capacitor
\
12μF/450V
12μF/450V
Speed (Hi/med/lo)
r/min
1,020/910/800
1,020/910/800
Coil
Type
\
Copper tube and aluminum fin
Tube size
mm
Ф9.52
Ф9.52
No. of rows
\
3
3
Fin spacing
mm
1.5
1.5
Tube pitch(a)×row pitch(b)
mm
25.4×22
25.4×22
Length× height
mm
1,202×406.4
1,202×406.4
Number of circuits
\
10
10
Controller
\
R51/E
R51/CE
Refrigerant pipe (Liquid/ Gas)
mm
Ф9.52/Ф22
Ф9.52/Ф22
Drain pipe size
mm
Ф41
Ф41
Dimension (W×H×D)
mm
1,443×450×846
1,443×450×846
Packing (W×H×D)
mm
1,549×476×917
1,549×476×917
Net/Gross weight
kg
105/120
105/120
Notes:
1. Nominal cooling capacities are based on the following conditions:
T1: Indoor temp: 27°CDB, 19°CWB; Outdoor temp: 35°CDB, 24°C WB; T3: Indoor temp: 27°CDB, 19°CWB; Outdoor
temp: 46°CDB; Equivalent refrigerant piping: 7.5m (horizontal).
2. Nominal heating capacities are based on the following conditions:
Indoor temp: 20°CDB, 15°C WB; Outdoor temp: 7°CDB, 6°CWB; Equivalent refrigerant piping: 7.5m (horizontal).
