INSTALLATION
16
PRODUCT INSTALLATION
Countertop Installation
Remove all packing material and accessories. Examine the oven for any damage such as
dents or broken door. Do not install if oven is damaged.
Cabinet: Remove any protective film found on the microwave oven cabinet surface. Do
not remove the Waveguide cover that is attached to the oven cavity to protect the
magnetron.
(5) Place the oven as far away from
radios and TV as possible.
Operation of microwave oven may
cause interference to your radio or TV
reception.
2. Plug your oven into a standard household
outlet. Be sure the voltage and the
frequency is the same as the voltage
and the frequency on the rating label.
WARNING: Do not install oven over a
range cooktop or other heat-producing
appliance. If installed near or over a heat
source, the oven could be damaged and
the warranty would be void.
1. Select a level surface that provide
enough open space for the intake
and/or outlet vents.
The accessible surface
may be hot during
operation.
20cm
30cm
20cm
min85cm
0cm
(1) The minimum installation height
is 85cm.
(2) The rear surface of appliance shall
be placed against a wall.
(3) Do not remove the legs from the
bottom of the oven.
(4) Blocking the intake and/or outlet
openings can or outlet openings
can damage the oven.
Leave a minimum clearance of 30cm
above the oven, a minimum clearance
of 20cm is required between the oven
and any adjacent walls.
Rinse the inside of the water box and drip
collector with water.
Uncover the water lid to clean, or drain the
remaining water.
