26
3
When installing the air conditioner on a new ceiling, affix a piece of cardboard to the
indoor unit of the installed air conditioner for reference to determine the size, location,
and center of the ceiling opening.
Evenly adjust the four hex nuts to make sure that the body of the air conditioner is level.
When the air conditioner is to be fixed onto the ceiling with a frame:
The horizontal distance of the overlapping part of the ceiling and decoration panel must be more than 10mm.
The distance between the indoor unit and the ceiling must be within 12mm. If the distance is greater than
15mm, retrofit the ceiling.
Fold the lugs in such a manner that the side with nothing printed on it protrudes. Otherwise, the mounting
cardboards cannot be installed.
Seven screws are included in the accessory package to models with a power of 3.6<kW≤7.1. Only six screws
are required for the mounting cardboard. Please retain the extra screw in case you need it at a later time.
The dimensions of the ceiling opening should be based on the opening of the mounting cardboard.
If Necessary, Cut Out An Opening For Installation On The Ceiling
(Where There Is An Existing Ceiling)
① Fold six mounting lugs.
② Install the mounting cardboard by using the installation screws for the panel.
CAUTION
CAUTION
CAUTION
