10
●
●
●
Remove the pan supports, the burner lid and flame spreader and carefully turn the
appliance upside down and place it on a cushioned mat.
Take care that the Ignition devices and flame supervision devices are not damaged in
this operation.
Apply the sponge provided around the edge of the appliance.
Do not leave a gap in the sealing agent or overlap the thickness.
Installing the appliance
Warning
Do not use a silicon sealant to seal the
appliance against the aperture.
This will make it dicult to remove the
appliance from the aperture in future,
particularly if it needs to be serviced.
1.
2.
3.
Place the bracket (B) over the holes that
match the size of the screws.There are one
set of screw holes in each corner of the hob
(H).Slightly tighten a screw (C) through the
bracket (B) so that the bracket is attached
to the hob, but so that you can still adjust
the position.
Carefully turn the hob back over and then
gently lower it into the aperture hole that
you have cut out.
On the underneath of the hob, adjust the
brackets into a position that is suitable for
your worktop.
Then fully tighten the screws (C) to secure
the hob into position.
(A) SEALING STRIP
(C) SCREW
(B) BRACKET
