15
Warning
Safety and Energy saving advice
The diameter of the bottom of the pan should correspond to that of the burner.
Triple-Crown
Rapid
Semi-rapid
Auxiliary
BURNERS
PANS
min.
200mm
200mm
160mm
120mm
220mm
220mm
180mm
160mm
max.
Do not use cookware that overlaps the edge of the burner.
(2) Installing the gas hob
This appliance should be installed by a registered Gas Safe Engineer!
Do not use too much force
when tightening; Otherwise,
it will cause elbow fracture or
rubber ring deformation and
leakage.
Note that the torque wrench
must be used to tighten with
a torque of 10N.m. The
maximum torque cannot
exceed 20N.m.
The watertight seal supplied must be inserted between the manifold outlet and the gas supply.
You must prevent the pipe from coming into contact with moving parts of the kitchen unit (for
example, a drawer) and prevent access to any spaces which might become obstructed.
Danger of leaks!
If any connection is handled, check the seal.
The manufacturer is not liable for any connection leaking, after being handled.
A fixed connection
Connection using a flexible pipe (L min. 1 m - max. 3 m)
Gas connection
The gas connection must be located in position where the stop tap is accessible.
The end of the inlet connection point of the gas hob has a 1/2" thread that allows for:
Warning
Do not use cast iron pans, clay or earthenware pots, grill pan, grill or toaster plates,
the resulting heat build-up may damage the appliance.
Do not touch the top plate and trivet whilst in use for a certain period after use.
As soon as a liquid starts boiling, turn down the flame so that it will barely keep the
liquid simmering.
Fats and oil when heated can release flammable vapours. Keep flames or heated
objects away from fats and oils when you cook with them.
Since the vapours that very hot oil releases can causes spontaneus combustions,
please watch your food during cooking.
