08
5.1 Align screw holes on the outer ring of both the front and rear guards,with the
positioning clip aligned as illustrated.
5 Front Guard Installation
Manually adjust the back cover of the motor up and down to adjust the pitch angle of
the fan.
6 Tilt angle adjustment
To make the fan oscillate, push down on the oscillation knob located on the top of the
motor housing. To stop the fan from oscillating, pull up the oscillating knob.
7 Oscillation control
Pull-up for static
Swing Pull-knob
Push-down to swing
5.2 Press down all the buckles to fasten the front guard with the rear guard. at the
screw holes, tighten the separated screw and nut.
Buckle
Manual
Tilt Adjustment
EN
