15
10. Undo the Back Cover
I. Undo the two screws fit
between Back Cover and Inlet
Valve;
II. Undo the white Fixed Seat and
separate the Tub Air Drain Hose
from the Back Cover;
III. Remove all screws on the
Back Cover;
IV. Separate the Back Cover from
the Cabinet;
V. If necessary, disconnect other
connections, such as plugs, drain
pipe, etc.
11. Undo the Pulley
I. Undo the Side Plate;
II. Rotate the pulley and at
the same time pull out the belt;
III. Remove the screw on the
pulley and then take down the
pulley.
12. Undo the Drain Pump
I. Undo the Side Plate;
II. Open the Lint Filter Door;
III. Remove the three screws;
IV. Release the clamps fixing the
Tub Drain Hose/Drain Pipe;
V. Pull out the two plugs and
then take out the Drain Pump.
5 UNPACKING WAYS OF MAIN PARTS
