04
EN
PRODUCT INSTALLATION
Install Instruction
For refrigerating appliances with climate class
• Depending on the climate class, this refrigerating appliance is intended to be
• The climate class can be found on the rating plate. The product may not
•
Effective temperature range
• The product is designed to operate normally in the temperature range
Class Symbol
Ambient temperature range °C
IEC 62552 (ISO 15502) ISO 8561
Extended temperate SN + 10 to + 32 + 10 to + 32
Temperate N + 16 to + 32 + 16 to + 32
Subtropical ST + 16 to + 38 + 18 to + 38
Tropical T + 16 to + 43 + 18 to + 43
Dimensions and Clearances
• Too small of a distance from adjacent items may result in the degradation
of freezing capability and increased electricity costs. Allow over 100 mm of
clearance from each adjacent wall when installing the appliance.
>10mm
>10mm
>100mm
>100mm
>700mm
>100mm
>100mm
>100mm
Top View
Required space
for air circulation
ATTENTION
on the physical
product or statement by the distributor.
