Service Manual_
23
7.2 Parts inside the refrigerator
Refrigerator Fruit box cover
Remove the crisper cover of ref. compartement accordin
g to below steps:
1） 1）Take out the crisper firstly.
Lift up the Fruit box cover, and then pull out it.
Shelves
Lift up the division plate with a proper force and pull it
out towards yourself;
Freezer Drawer
The drawer is located at the freezing chambers;
1) Pull the drawer out completely;
2) Lift it up slightly and take it out from the refrigerator.
7.3 Light system
Light
Light of the refrigerating chamber is located upper
chamber(inner display)
1）Remove the lamp cover
2）Remove the light.
3) The reverse process can complete installation.
