04
EN
PRODUCT INSTALLATION
Install Instruction
For refrigerating appliances with climate class
• Depending on the climate class, this refrigerator is intended to be used at an
ambient temperature range as specified in the following table.
• The climate class can be found on the rating plate. The product may not
operate properly at temperatures outside of the specific range.
• You can find the climate class on the product label.
Eective temperature range
• The product is designed to operate normally in the temperature range
specified by its class rating.
Class Symbol
Ambient temperature range °C
IEC 62552 (ISO 15502) ISO 8561
Extended temperate SN + 10 to + 32 + 10 to + 32
Temperate N + 16 to + 32 + 16 to + 32
Subtropical ST + 16 to + 38 + 18 to + 38
Tropical T + 16 to + 43 + 18 to + 43
Dimensions and Clearances
• Too small of a distance from adjacent items may result in the degradation of
freezing capability and increased electricity costs. the refrigerator both sides
should be placed against the wall with a free distance more than 100mm, and
the refrigerator back against the wall distance not more than 75 mm.
>100mm
>100mm
>100mm
>100mm
>100mm
≤75mm
Top View
Required space
for air circulation
ATTENTION
The picture above is only for reference. The actual configuration will depend on the physical
product or statement by the distributor.
