MCEID-09 MCEID-12
MCEID-18
V-Ph-Hz
Btu/h
9300 (4305-10986) 12300 (5600-13000) 18000 (8380-21200）
W
24.0 24.0 30.0
A
0.11 0.11 0.14
Built In
Built In
Built In
m3/h
650 / 560 / 450 / 350 700 / 610 / 520 / 400 900 / 800 / 600 / 500
dB(A)
35.5 / 29.5 / 21.0 37.5 / 32.5 / 26.5 40.5 / 34.5 / 30.5
mm
795 x 225 x 295 795 x 225 x 295 965 x 239 x 319
mm
870 x 370 x 305 870 x 370 x 305 1045 x 400 x 325
Kg
10.3 / 13.1 10.3 / 13.1 12.3 / 16.2
mm
6.35 / 9.52 6.35 / 9.52 6.35 / 12.70
inch
1/4" / 3/8" 1/4" / 3/8" 1/4" / 1/2"
Drain
mm
19 19 19
°C
16~30 16~30 16~30
m²
12～23 16～23 23～33
Opera�on Temperature
Applica�on Area
Indoor Sound Level (H / M / L)
Dimension (W x D x H)
Packing (W x D x H)
Net / Gross Weight
Piping
Liquid / Gas
Capacity
Input
Rated Current
Wifi Port
Indoor Air Flow (Turbo / H / M / L)
Model
Model - Indoor Unit (Premium)
Power supply
220-240V / 1Ph / 50Hz
Indoor Units
Outdoor Units
MCE-4M28E
V-Ph-Hz
Btu/h
28000 (4606 - 31220)
KW
7.50 (1.35 - 9.15)
W
1540
(5.03 / 6.22)
A
6.8
Kg
R32 / 1.7
dB(A)
50 - 56
Dimension (W x D x H)
mm
890 x 342 x 673
Packing (W x D x H)
mm
1030 x 438 x 750
Net / Gross Weight
Kg
45.2 / 48.5
mm
6.35 (x4) / 9.52 (x4)
inch
1/4" (x4) / 3/8" (x4)
Max. Length
m
35
Max. Height
m
15
Drain
mm
19
℃
Opera�on temperature
220-240V / 1Ph / 50Hz
16~30
Model
Outdoor Unit
Piping
Liquid / Gas
Input
COP (Full / Weighted)
Rated Current
Refrigerant Type
Outdoor Sound Level
Capacity
Model - Outdoor Unit
Power supply
Operation Indoor A Room B Room C Room D Room
Rated
Min. Max. Min. Rated Max. Min. Rated Max.
9 2.60 - - - 2.60 1.35 3.35 2.26 2.82 4.52 0.47 0.59 0.95
12 3.50 - - - 3.50 1.35 3.80 2.26 4.12 5.19 0.48 0.86 1.09
18 5.30 - - - 5.30 1.35 5.60 2.26 6.47 7.76 0.48 1.36 1.63
24 6.10 - - - 6.10 1.38 6.20 2.30 7.14 8.57 0.49 1.50 1.80
9+9 2.60 2.60 - - 5.20 1.41 5.80 2.34 5.84 8.63 0.50 1.24 1.83
9+12 2.60 3.50 - - 6.10 1.43 6.32 2.37 6.77 9.39 0.50 1.44 1.99
9+18 2.55 4.50 - - 7.05 1.52 7.30 2.52 8.99 10.85 0.53 1.91 2.30
9+24 2.10 5.00 - - 7.10 1.54 7.40 2.53 9.05 10.95 0.54 1.92 2.32
12+12 3.50 3.50 - - 7.00 1.53 7
.25 2.53 9.05 10.80 0.54 1.92 2.29
12+18 3.15 4.00 - - 7.15 1.57 7.40 2.61 8.99 10.99 0.55 1.91 2.33
18+18
3.60 3.60 - - 7.20 1.57 7.45 2.61 8.71 11.08 0.55 1.85 2.35
9+9+9 2.35 2.35 2.35 - 7.05 1.63 8.00 2.67 7.63 11.52 0.57 1.64 2.48
9+9+12 2.24 2.24 2.67 - 7.15 1.63 8.10 2.68 7.65 11.66 0.57 1.64 2.51
9+9+18 2.06 2.06 3.08 - 7.20 1.63 8.20 2.66 7.61 12.02 0.57 1.64 2.59
9+9+24 1.70 1.70 4.10 - 7.50 1.64 9.00 2.68 8.39 12.16 0.58 1.80 2.61
9+12+12 2.11 2.52 2.52 - 7.15 1.62 8.15 2.65 7.56 11.77 0.57 1.63 2.53
9+12+18 1.95 2.33 2.92 - 7.20 1.63 8.25 2.66 7.61 12.10 0.57 1.64 2.60
9+12+24 1.46 1.95 3.89 - 7.30 1.63 9.05 2.67 7.63 12.16 0.57 1.64 2.62
9+18+18 1.80 2.7
5 2.75 - 7.30 1.63 8.40 2.67 7.63 12.15 0.57 1.64 2.61
12+12+12 2.40 2.40 2.40 - 7.20 1.63 8.20 2.66 7.61 12.02 0.57 1.64 2.59
12+12+18 2.21 2.21 2.78 - 7.20 1.63 8.30 2.63 7.53 12.10 0.57 1.62 2.60
9+9+9+9 1.88 1.88 1.88 1.88 7.52 1.75 9.00 2.72 6.80 11.50 0.62 1.54 2.61
9+9+9+12 1.79 1.79 1.79 2.15 7.52 1.75 9.05 2.72 6.80 11.56 0.62 1.54 2.63
9+9+9+18 1.69 1.69 1.69 2.53 7.60 1.76 9.15 2.73 6.83 11.62 0.62 1.55 2.64
9+9+12+12 1.71 1.71 2.05 2.05 7.52 1.75 9.10 2.72 6.80 11.56 0.62 1.54 2.63
9+12+12
+12 1.64 1.96 1.96 1.96 7.52 1.75 9.15 2.72 6.80 11.56 0.62 1.54 2.63
9+9+12+18 1.51 1.51 1.85 2.93 7.80 1.75 9.15 2.72 6.80 11.56 0.62 1.54 2.63
9+9+9+24 1.39 1.39 1.39 3.72 7.90 1.76 9.20 2.73 6.83 11.62 0.62 1.55 2.64
2 Rooms
3 Rooms
Running Current (Amp)
1 Room
4 Rooms
MCE-4M28E Cooling Capacity (KW) Total Capacity (KW) Input (KW)
CAPACITY TABLE
