05
≥
5
Native appliance
Native appliance
Without hob
Hob
575
≥
5
≥
5
A
With hob
575
≥
5
595
595
20
401
Minimum bottom ventilation area: 250 mm
2
*
Min. 450
If the appliance is installed under the hob, the minimum
thickness of worktop A is shown below:
600
Min. 50
600
+2
Min. 470
+8
560
Air vents
Hob type
Induction hob 37 mm
worktop A
Full-surface induction hob 47 mm
Gas hob
Electric hob
30 mm
27 mm
5
20
20
Reserve 5 mm for the door panel at the top and
bottom respectively.
Reserve 20 mm for the door panel on the left
and right respectively.
Reserve 20 mm for the door panel in thickness.
Cupboard Diagram (Ground Cupboard)
1.
2.
3.
The thickness of the cupboard board is 20 mm.
If the power socket is installed on the back of the appliance, the depth of the
cupboard opening shall be increased from a minimum of 470 mm to 500 mm.
The dimensions in the figures are in mm.
