15
ＲＩＧＨＴ
ＬＥＦＴ
1
Together with your helper,
lift the assembled AC into
the window frame.
Make sure you do this step with a helper. Very carefully, lift
the assembled AC into the window frame. Make sure someone
is holding the back of the unit securely.
*It’s helpful to rest the unit on the inside window sill until you’re
ready to reposition it correctly. Injury (to you and others) and
property damage can occur if not done correctly.
*Check that air conditioner is tilted back about 3°to 4°downward to the
outside. After proper installation, condensate should not drain from the
overflow drain hole during normalu se,correct the slope otherwise.
2
Properly position the bottom bar
BEHIND the inside window sill.
Properly position the bottom bar behind the inside window sill and into the
bottom horizontal channel of the window frame. The front of the bottom bar
should be pressing up against the back edge of the sill.
Wooden Windows
Angle：3-4°
Outside
Outside
Inside
Inside
Vinyl-Clad Windows
Angle：3-4°
Lift the AC into the window.
