Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
3
ACCESSORIES
The system is shipped with the following accessories (see Table 1). Use all of the installation parts and accessories to install the system. Improper installation
may result in water leakage, electrical shock and fire, or cause the equipment to fail. Keep the installation manual in a safe place and do not discard any other
accessories until the installation work has been completed.
seirosseccA — 2 elbaTseirosseccA — 1 elbaT
NAME SHAPE QUANTITY
3-2launaM noitallatsnI
1tnioJ niarD
Seal (for cooling and
heating models)
1
1etalP gnitnuoM
Anchor
5-8 (depending
on models)
Mounting Plate Screw
5-8 (depending
on models)
1rellortnoC etomeR
2yrettaB
Remote Controller
Holder (optional)
1
Remote Controller
Holder Screw (optional)
2
Small Filter
(Must be installed on the
back of the main air filter
by an authorized
technician during unit
installation)
1-2 depending
on the model
FROM EDGE TO HOLE CENTER:50mm
FROM EDGE TO HOLE CENTER:100mm
150
100
100
100
50
50
50
2
2
2
4
4
4
6
RECOMMAND
LIQUID
GAS
BUBBLE
LEVEL
mm
inch
mm
inch
Swing
Boost
Clean
NAME SHAPE QUANTITY (PC)
Connecting
Pipe Assembly
Liquid
Side
1/4in(Φ 6.35)
These parts must
be purchased
separately. Consult
the dealer about the
proper pipe size of
the unit purchased.
3/8in (Φ 9.52)
Gas Side
3/8in (Φ 9.52)
1/2in (Φ12.7)
5/8in (Φ16)
3/4in (Φ19)
Magnetic Ring and
Clamp (if supplied
refer to the wiring
diagram to install it
to the cable.
Varies by model
1 2 3
Pass the cable
through the
Magnetic Ring hole.
