PARTS LIST
1 - (I)COMP-COOL50P
1 - 12V 1A POWER SUPPLY
1 - ALCOHOL WIPE
5 - WIRE TIES
5 - WIRE TIE SADDLES
(I)COMP-COOL50P
POSITIONING
- The (I)COMP-COOL50P blower comes factory installed facing the front of the unit (17” width)
(432 mm). It can be repositioned by removing the four Phillips head screws securing it in place. It can
be relocated to face three other positions (see page 5).
1) Choose 17” (432 mm) or 14” (356 mm) dimension for the front, depending on the depth of the
components below or above the (I)COMP-COOL50P.
WEIGHT RATING: 150 lbs (68 kg). The weight
must be within 2” (51 mm) of all outer edges. Any
components or shelving supporting the
(I)COMP-COOL50P MUST be able to support
150 lbs (68 kg).
Page 4
2 ⅛”
(54 mm)
2” (51 mm)
2) Locate the hot-spot. Aim the unit toward desired opening in the rack to exhaust hot air, or aim the
unit toward source of forced ventilation.
3) To ensure the unit is level and properly spaced, the rubber feet may be relocated to one of slots on
the bottom.
- Wire ties and wire tie saddles are provided for cable management.
17” (432 mm) 14” (356 mm)
DIMENSIONS
(EXHAUST DEFAULT)
TOP VIEW
17” (432 mm)
14”
(356 mm)
