SPEICIFICATIONS
• Protective Eyewear
• Power Driver
• 9/16” Socket
• 7/16” Socket
• ⅜” Socket
• Slip Joint Pliers
• #2 Flat Head Screwdriver
• #2 Phillips Screwdriver
REQUIRED TOOLS
WARNING: Use tools with caution and follow all necessary safety
protocols.
AVERTISSEMENT: Utiliser des outils avec prudence et suivre
tous les protocoles de sécurité nécessaires.
SUPPLIED COMPONENTS AND HARDWARE
Width: 23.4” (594 mm)
Height: 10 RU - 35 RU
Depth: 17” (432 mm), 22” (559 mm), 26” (660 mm)*, and 32” (813 mm)*
* Available for certain heights only
NOTE:
• To order more hardware, contact support at av.support@legrand.com or (866) 977-3901.
• Additional hardware is included that may not be required for your installation.
If any pieces are missing or damaged, please report it immediately to Technical Support at
av.support@legrand.com or (866) 977-3901.
Backpan
A
Trim
C
Center Section
B
(2x)
8-32 Nut
F
(2x)
8-32 Stud
D
(16x)
10-32 Cage Nut
G
NOTE: Cage nuts are included
for installations where center hole
mounting is required.
Latch Back
E
