INTRODUCTION
Page 7
NOTE:
• Please take the time to carefully unpack and inspect all components and gather all corresponding
instruction sheets.
• Instruction sheets may also be accessed at www.legrandav.com.
• Maintenance and care information is provided in Care and Cleaning of Products (I-00788) and
Unpacking and Handling Precautions (I-00787) for your convenience.
Color Options: The C5 Credenza is available in a variety of color options. For more information, refer
to www.legrandav.com.
Review notes regarding the anti-tip feet before assembling your credenza.
• FOR 2- AND 3-BAY C5-FF22-X MODELS ONLY: Install the rear anti-tip feet before proceed-
ing. For more information, refer to “Installing Rear Anti-Tip Feet (C5-FF22-X Models Only)” on
page 9.
• Rear anti-tip feet are pre-installed on 1-bay models.
• Front anti-tip feet are pre-installed on all models.
• For more information regarding how to lower the front and rear anti-tip feet, refer to “Lowering
Front and Rear Anti-Tip Feet” on page 9.
C5 Series Documentation Set:
Refer to the following instruction sheets to install the C5 Series options you may have purchased for
your credenza.
• Rear Bay Extender Installation Instruction Sheet (I-00701)
• Shelf System Insert Instruction Sheet (I-00500)
• Large Format Display Mount System Instruction Sheet (I-00749)
• Flip-Up Side Shelf Instruction Sheet (I-00689)
• C5 Adjustable Rear Rail Brackets Instruction Sheet (I-00730)
• Rotating Sliding Rail System for C5-D Deep Credenza Rack (I-00573)
• Anti-Tip Feet Field Installation for Rotating Sliding Rail System (100-00019)
• Waste Basket Insert Instruction Sheet (I-00498)
• Replacement Blower Kit Instruction Sheet (100-00021)
• Millwork Kit Drawings Instruction Sheet (I-00733)
• Review Woodworker's Kit Page on www.legrandav.com and perform the installation.
▪ If you are providing your own woodwork for your credenza , access the Woodworker's Kit page
at:
https://www.legrandav.com/c5-woodworkers-kit
▪ Download a .zip file of engineering drawings by clicking the C5 part number that corresponds
with the width, hardware finish, and frame style of your lectern.
▪ When reviewing the drawings provided in the .zip file, analyze the frame measurements and
dimensions for the C5 Series Woodkit (the one that we sell) when creating your own custom
woodkit.
