FlashPro Express User Guide
47
I
OL
Low-level
output
current
1.65V to
1.95V
8
mA
2.3 V to 2.7 V
9
mA
3 V to 3.6 V
12
mA
DC Characteristics for FlashPro5/4/3/3X
Note: The target board must provide the VCC, VCCI, VPUMP, and VJTAG during programming.
Note: The VJTAG signal is driven from the target/DUT board. The VJTAG pin is sensed by the FP4 to
configure the internal input and output buffers to the same IO Voltage levels. The VJTAG pin is only
an input pin to the programmer.
Table 3 · DC Characteristic for FlashPro5/4/3/3X
Description Symbol Min Max Unit
Input low voltage, TDO VIL -0.5 0.35*VJTAG V
Input high voltage, TDO VIH 0.65*VJTAG 3.6 V
Input current, TDO IIL, IIH -20 +20 mA
Input capacitance, TDO
40 pF
Output voltage, VPUMP, operating VPP +3.0 +3.6 V
Output current, VPUMP IPP
250 mA
VJTAG = 1.5V
Output low voltage, TCK, TMS, TDI, 100µA load VOL 0.0 0.2 V
Output low voltage, TCK, TMS, TDI, 4mA load VOL 0.0 0.30*VJTAG V
Output high voltage, TCK, TMS, TDI, 100µA load V VJTAG-0.2 VJTAG V
Output high voltage, TCK, TMS, TDI, 4mA load VOH 0.70*VJTAG VJTAG V
Output current, TCK, TMS, TDI IOL, IOH -4 +4 mA
VJTAG = 1.8V
Output low voltage, TCK, TMS, TDI, 100µA load VOL 0.0 0.2 V
Output low voltage, TCK, TMS, TDI, 6mA load VOL 0.0 0.3 V
Output high voltage, TCK, TMS, TDI, 100µA load VOH VJTAG-0.2 VJTAG V
Output high voltage, TCK, TMS, TDI, 6mA load VOH 1.25 VJTAG V
Output current, TCK, TMS, TDI IOL, IOH -6 +6 mA
VJTAG = 2.5V
Output low voltage, TCK, TMS, TDI, 100µA load VOL 0.0 0.2 V
