FlashPro Express User Guide
35
Error Code Exit Message Possible Cause Possible Solution
datasheet for more information on transient
specifications.
Monitor JTAG supply pins during
programming; measure JTAG signals for noise
or reflection.
0x8008 Device is blank Attempting to verify digest
of a blank device
Program the device prior to running action
"VERIFY_DIGEST"
0x8009
FPGA array digest
check is disabled
Digest check has been
disabled by
"Programming Bitstream
Settings" tool within
Libero
Drive TRSTB high during device power up.
Enable digest check in "Programming Bitstream
Settings" tool within Libero and reprogram the
device.
0x800A Failed to verify digest:
Instruction timed out
Unstable voltage level
Signal integrity
issues on JTAG pins
Try running VERIFY_DIGEST action again.
Monitor related power supplies that cause the
issue during programming; check for transients
outside of Microsemi specifications. See your
device datasheet for more information on
transient specifications.
Monitor JTAG supply pins during
programming; measure JTAG signals for noise
or reflection.
0x800B
FPGA Fabric digest
verification: FAIL
Programming
bitstream components
do not match
components
programmed
FPGA Fabric is either
erased or the data has
been corrupted or
tampered with
Use the same programming file that was
used to program the device.
0x800C Factory row segment
digest verification: FAIL
Programming
bitstream components
do not match
components
programmed
Factory row segment data
has been corrupted or
tampered with
Use the same programming file that was
used to program the device.
