FlashPro Express User Guide
24
1.1 Enable/Disable device for programming
The option allows the device to be enabled or disabled (put in “bypass”).
The user must load the programming file when enabling a device that is currently in “bypass”, with no
programming file associated with the device or SPI-Flash. As a result, the device header info tooltip is updated
with selected programming action, if enabled, or “bypass”, if disabled.
Notes:
• The job cannot be saved if there is all devices are disabled or if any of enabled devices does not have
loaded programming file.
• If all the devices are disabled an actions combo box and a “run” button are disabled.
1.2 Load Programming File
The option is available for the enabled devices to load a different programming file for the target device.
FlashPro Express requires all programming files to be in the local job folder. When loading a programming file
from outside the job folder the file will be copied to the job folder first and then loaded for the selected device.
The user must confirm copying the programming file to the job folder and overwriting the existing file.
1.3 Select a programming action and configure actions and procedures per device
The option allows the selection of the programming action and configuration of the actions’ procedures. The
option is available for an enabled device that has programming file loaded, and when the “Run selected action
for all devices” option is unselected.
1.4 Load SPI Flash file
This option allows the user to load a different SPI Flash programming file.
1.5 Select SPI Flash Action
The option allows the selection of the programming action for the SPI Flash. The option is available for the
enabled device that has SPI Flash Programming File loaded, and when the “Run selected action for all devices”
option is unselected.
