FlashPro Express User Guide
36
Error Code Exit Message Possible Cause Possible Solution
0x800D
Bitstream Error.
Bitstream or data is
corrupted or noisy.
Bitstream file has
been corrupted
Bitstream was
incorrectly generated
Unstable voltage level
Signal integrity
issues on JTAG pins
Regenerate bitstream file
Monitor related power supplies that cause the
issue during programming; check for transients
outside of Microsemi specifications. See your
device datasheet for more information on
transient specifications.
Monitor JTAG supply pins during
programming; measure JTAG signals for noise
or reflection.
0x800E
Failed to query
programming bitstream
settings: Instruction
timed out
Unstable voltage level
Signal integrity
issues on JTAG pins
Try running DEVICE_INFO action again.
Monitor related power supplies that cause the
issue during programming; check for transients
outside of Microsemi specifications. See your
device datasheet for more information on
transient specifications.
Monitor JTAG supply pins during
programming; measure JTAG signals for noise
or reflection.
0x800F
Bitstream Error. Incorrect
DEVICEID
Incorrect programming file
Incorrect device in chain
Signal integrity
issues on JTAG pins
Choose the correct programming file and select
the correct device in the chain.
Measure JTAG pins and noise for reflection. If
TRST is left floating then add pull-up to pin.
Reduce the length of Ground connection.
0x8010
Operation has been
disabled by
programming bitstream
settings
Operation has been
disabled by
"Programming Bitstream
Settings" tool within
Libero
User disabled Fabric
Erase/Write/Verify
and attempted to
Erase/Program/Verify
the device
Drive TRSTB high during device power up
Enable the disabled operation in the
"Programming Bitstream Settings" tool with
Libero and reprogram the device
