FlashPro Express User Guide
32
Error
Code
Exit Message
Exit
Code
Possible Cause Possible Solution
Bitstream or data is
corrupted or noisy
Unstable voltage level.
Signal integrity issues on
JTAG pins.
issue during programming; check for transients
outside of Microsemi specifications. See your
device datasheet for more information on
transient specifications.
Monitor JTAG supply pins during programming;
measure JTAG signals for noise or reflection.
0x8021 Programming Error.
Invalid/Corrupted
encryption key
-23 File contains an encrypted
key that does not match the
device
File contains user
encryption key, but device
has not been programmed
with the user encryption key
Provide a programming file with an encryption
key that matches that on the device
First program security with master programming
file, then program with user encryption 1/2 field
update programming files
0x8023 Programming Error.
Back level not
satisfied
-24 Design version is not higher
than the back-level
programmed device
Generate a programming file with a design
version higher than the back level version
0x8001 Failure to read DSN -24
Device is in System
Controller Suspend Mode
Check board connections
TRSTB should be driven High or disable
"System Controller Suspend Mode".
0x8027 Programming Error.
Insufficient device
capabilities
-26 Device does not support the
capabilities specified in
programming file
Generate a programming file with the correct
capabilities for the target device
0x8029
Programming Error.
Incorrect DEVICEID
-27 Incorrect programming file
Incorrect device in chain
Signal integrity issues on
JTAG pins
Choose the correct programming file and select
the correct device in chain
Measure JTAG pins and noise or reflection. If
TRST is left floating, then add pull-up to pin
Reduce the length of ground connection
0x802B Programming Error.
Programming file is
out of date, please
regenerate.
-28
Programming file version is
out of date
Generate programming file with latest version of
Libero SoC
0x8030 Programming Error
Invalid or inaccessible
Device Certificate
-31 FAB_RESET_N is tied to
ground
FAB_RESET_N should be tied to HIGH
0x8032
0x8034
0x8036
0x8038
Instruction timed out -32 Unstable voltage level
Signal integrity issues on
JTAG pins
Monitor related power supplies that cause the
issue during programming; check for transients
outside of Microsemi specifications. See your
device datasheet for more information on
transient specifications.
