FlashPro Express User Guide
33
Error
Code
Exit Message
Exit
Code
Possible Cause Possible Solution
Monitor JTAG supply pins during programming;
measure JTAG signals for noise or reflection.
0x8010 Failed to unlock user
pass key 1
-35 Pass key in file does not
match device
Provide a programming file with a pass key that
matches pass key programmed into the device.
0x8011
Failed to unlock user
pass key 2
-35
Pass key in file does not
match device
Provide a programming file with a pass key that
matches pass key programmed into the device.
0x804F
Bitstream
programming action is
disabled
-38 Unstable voltage level
Bitstream programming
action has been disabled in
Security Policy Manager
Monitor related power supplies that cause the
issue during programming; check for transients
outside of Microsemi specifications. See your
device datasheet for more information on
transient specifications.
Need to use a bitstream file which has a
valid FlashLock/UPK1 to enable the
bitstream programming action.
0x805B
Error, security must
be either programmed
on a blank device or
with the FPGA Fabric
design
-42
Security only bitstream
programming on a
programmed device
Use this bitstream on a blank device or
generate a new bitstream that contains the
FPGA Fabric design along with the security
Exit Codes (RTG4)
Error Code Exit Message Possible Cause Possible Solution
Passed (no error)
-
-
0x8001
Failure to read DSN Device is in System
Controller Suspend Mode
Check board connections
TRSTB should be driven High on device power
up.
Disable System Controller Suspend Mode in
"Programming Bitstream Settings' tool within
Libero and reprogram the device.
0x8002 Device is busy Unstable VDDIx voltage
level
Monitor related power supplies that cause the
issue during programming; check for transients
outside of Microsemi specifications. See your
device datasheet for more information on
transient specifications.
0x8003 Failed to enter
programming mode
Unstable voltage level
Signal integrity issues on
Monitor related power supplies that cause the
issue during programming; check for transients
