FlashPro Express User Guide
30
Error
Code
Exit Message
Exit
Code
Possible Cause Possible Solution
Failed to verify sNVM
Monitor JTAG supply pins during programming;
measure JTAG signals for noise or reflection.
0x8013
External digest check
via JTAG/SPI Slave is
disabled.
-18
External Digest check via
JTAG/SPI Slave is disabled.
Need to use a bitstream file which has a valid
FlashLock/UPK1 to enable external digest
check via JTAG/SPI Slave.
0x8015
FPGA Fabric digest
verification: FAIL
Deselect procedure
'DO_ENABLE_FABRI
C' to remove this
digest check.
-20
FPGA Fabric is either
erased or the data has been
corrupted or tampered with
If the Fabric is erased, deselect procedure
"DO_ENABLE_FABRIC" from action
"VERIFY_DIGEST"
0x8016
sNVM digest
verification: FAIL
Deselect procedure
'DO_ENABLE_SNVM'
to remove this digest
check.
-20
sNVM is either erased or the
data has been corrupted or
tampered with
If the sNVM is erased, deselect procedure
"DO_ENABLE_SNVM" from action
"VERIFY_DIGEST"
0x8018
User security
policies segment
digest verification:
FAIL
Deselect procedure
'DO_ENABLE_SECU
RITY' to remove this
digest check.
-20
Security segment is either
erased or the data has been
corrupted or tampered with
If the security is erased, deselect procedure
"DO_ENABLE_SECURITY" from action
"VERIFY_DIGEST"
0x8019
UPK1 segment digest
verification: FAIL
Deselect procedure
'DO_ENABLE_SECU
RITY' to remove this
digest check.
-20
UPK1 segment is either
erased or the data has been
corrupted or tampered with
If the UPK1 is erased, deselect procedure
"DO_ENABLE_SECURITY" from action
"VERIFY_DIGEST"
0x801A UPK2 segment digest
verification: FAIL
Deselect procedure
'DO_ENABLE_UKS2'
to remove this digest
check.
-20 UPK2 segment is either
erased or the data has been
corrupted or tampered with
If the UPK2 is erased, deselect procedure
"DO_ENABLE_UKS2" from action
"VERIFY_DIGEST"
0x801B Factory row and
factory key segment
digest verification:
FAIL
-20 Factory row and factory key
segment have been erased
through zeroization or the
data has been corrupted or
tampered with
