FlashPro Express User Guide
29
Troubleshooting
Exit Codes (PolarFire)
Error
Code
Exit Message Exit
Code
Possible Cause Possible Solution
Passed (no error)
0
-
-
0x8002
Failed to disable
programming mode
Failed to set
programming mode
5
Unstable voltage level
Signal integrity issues on
JTAG pins
Monitor related power supplies that cause the
issue during programming; check for transients
outside of Microsemi specifications. See your
device datasheet for more information on
transient specifications.
Monitor JTAG supply pins during programming;
measure JTAG signals for noise or reflection.
0x8032 Device is busy
5
Unstable VDDIx voltage
level
Monitor related power supplies that cause the
issue during programming; check for transients
outside of Microsemi specifications. See your
device datasheet for more information on
transient specifications.
0x8003
Failed to enter
programming mode
5
Unstable voltage level
Signal integrity issues on
JTAG pins
DEVRST_N is tied to LOW
Monitor related power supplies that cause the
issue during programming; check for transients
outside of Microsemi specifications. See your
device datasheet for more information on
transient specifications.
Monitor JTAG supply pins during programming;
measure JTAG signals for noise or reflection.
Tie DEVRST_N to HIGH prior to programming
the device.
0x8004 Failed to verify
IDCODE
6
Incorrect programming file
Incorrect device in chain
Signal integrity issues on
JTAG pins
Choose the correct programming file and select
the correct device in the chain.
Measure JTAG pins and noise for reflection. If
TRST is left floating then add pull-up to pin.
Reduce the length of Ground connection.
0x8005
0x8006
0x8007
0x8008
Failed to verify FPGA
Array
Failed to verify Fabric
Configuration
Failed to verify
Security
11 Device is programmed with
a different design or the
component is blank.
Unstable voltage level.
Signal integrity issues on
JTAG pins.
Verify the device is programmed with the
correct data/design.
Monitor related power supplies that cause the
issue during programming; check for transients
outside of Microsemi specifications. See your
device datasheet for more information on
transient specifications.
