AC Switching Characteriscs
Data Sheet
© 2024 Microchip Technology Inc. and its subsidiaries
DS00003831E - 31
...........continued
Standard STD –1 Unit
LVTTL 500 500 Mbps
LVCMOS33 500 500 Mbps
LVCMOS25 500 500 Mbps
LVCMOS18 500 500 Mbps
LVCMOS15 500 500 Mbps
LVCMOS12 300 300 Mbps
MIPI25
3
1000 1500 Mbps
1. All SSTLD/HSTLD/HSULD/LVSTLD/POD type receivers use the LVDS dierential receiver.
2. Performance is achieved with V
ID
≥200 mV.
3. V
ID
≥ 200 mV, V
ICM
≥100 mV, T
j
= 0.4 UI.
4. LVDS25 conguration should be used in conjunction with I/O CDR when implementing SGMII
receivers.
5.1.4 Output Buer Speed
The following tables describe output buer speed.
–STD speed grade is oered for Extended Commercial (E), Industrial (I), Military (M), and Automotive
(T2) temperature grades.
–1 speed grade is oered for Extended Commercial (E), Industrial (I), and Automotive (T2)
temperature grades only.
Table 5-5. HSIO Maximum Output Buer Speed
Standard STD –1 Unit
SSTL18I 800 1066 Mbps
SSTL18II 800 1066 Mbps
SSTL18I (dierential) 800 1066 Mbps
SSTL18II (dierential) 800 1066 Mbps
SSTL15I 1066 1333 Mbps
SSTL15II 1066 1333 Mbps
SSTL15I (dierential) 1066 1333 Mbps
SSTL15II (dierential) 1066 1333 Mbps
SSTL135I 1066 1333 Mbps
SSTL135II 1066 1333 Mbps
SSTL135I (dierential) 1066 1333 Mbps
SSTL135II (dierential) 1066 1333 Mbps
HSTL15I 900 1100 Mbps
HSTL15II 900 1100 Mbps
HSTL15I (dierential) 900 1100 Mbps
HSTL15II (dierential) 900 1100 Mbps
HSTL135I 1066 1066 Mbps
HSTL135II 1066 1066 Mbps
