AC Switching Characteriscs
Data Sheet
© 2024 Microchip Technology Inc. and its subsidiaries
DS00003831E - 37
Table 5-12. I/O Digital Transmit Double Data Rate Switching Characteriscs
Parameter Interface Name Topology I/O
Type
STD
(MHz)
–1
(MHz)
STD
(Mbps)
–1
(Mbps)
Forwarded Clock-to-
Data Skew
Output F
MAX
TX_DDR_G_A Tx DDR HSIO,
GPIO
500 500 1000 1000 From a global clock
source, aligned
TX_DDR_G_C Tx DDR HSIO,
GPIO
500 500 1000 1000 From a global clock
source, centered
Output F
MAX
2:1 TX_DDRX_B_A Tx DDR digital
mode
HSIO 400 500 800 1000 From a HS_IO_CLK
clock source, aligned
Output F
MAX
4:1
Output F
MAX
5:1
TX_DDRX_B_A Tx DDR digital
mode
HSIO 667 800 1333 1600 From a HS_IO_CLK
clock source, aligned
Output F
MAX
2:1 TX_DDRX_B_C Tx DDR digital
mode
HSIO 400 500 800 1000 From a HS_IO_CLK
clock source,
centered with PLL
Output F
MAX
4:1
Output F
MAX
5:1
TX_DDRX_B_C Tx DDR digital
mode
HSIO 667 800 1333 1600 From a HS_IO_CLK
clock source,
centered with PLL
Output F
MAX
2:1 TX_DDRX_B_A Tx DDR digital
mode
GPIO 400 500 800 1000 From a HS_IO_CLK
clock source, aligned
Output F
MAX
4:1
Output F
MAX
5:1
TX_DDRX_B_A Tx DDR digital
mode
GPIO 625 800 1250 1600 From a HS_IO_CLK
clock source, aligned
Output F
MAX
2:1 TX_DDRX_B_C Tx DDR digital
mode
GPIO 400 500 800 1000 From a HS_IO_CLK
clock source,
centered with PLL
Output F
MAX
4:1
Output F
MAX
5:1
TX_DDRX_B_C Tx DDR digital
mode
GPIO 625 800 1250 1600 From a HS_IO_CLK
clock source,
centered with PLL
Output F
MAX
4:1 TX_DDRX_B_C_
MIPI
Tx DDR digital
mode for MIPI
GPIO 500 500 1000 1000 From a HS_IO_CLK
clock source,
centered with PLL
–STD speed grade is oered for Extended Commercial (E), Industrial (I), Military (M), and Automotive
(T2) temperature grades.
–1 speed grade is oered for Extended Commercial (E), Industrial (I), and Automotive (T2)
temperature grades only.
Table 5-13. Programmable Delay
Parameter STD Min STD Typ STD Max –1 Min –1 Typ –1 Max Unit
In delay, out delay, DLL delay step sizes 12.7 30 35 12.7 25 29.5 ps
Note: Refer to Libero timing reports for conguration specic intrinsic and incremental delays.
