AC Switching Characteriscs
Data Sheet
© 2024 Microchip Technology Inc. and its subsidiaries
DS00003831E - 35
Table 5-9. I/O Digital Receive Single-Data Rate Switching Characteriscs
1
Parameter Interface
Name
Topology I/O Type STD
(MHz)
–1 (MHz) STD
(Mbps)
–1 (Mbps) Clock-to-Data
Condition
Input F
MAX
RX_SDR_G_A Rx SDR HSIO, GPIO 500 500 500 500 From a global clock
source, aligned
Input F
MAX
RX_SDR_R_A Rx SDR HSIO, GPIO 250 250 250 250 From a regional clock
source, aligned
Input F
MAX
RX_SDR_G_C Rx SDR HSIO, GPIO 500 500 500 500 From a global clock
source, centered
Input F
MAX
RX_SDR_R_C Rx SDR HSIO, GPIO 250 250 250 250 From a regional clock
source, centered
1. Unless otherwise noted, all data rates listed are achieved with static IOD tap settings.
–STD speed grade is oered for Extended Commercial (E), Industrial (I), Military (M), and Automotive
(T2) temperature grades.
–1 speed grade is oered for Extended Commercial (E), Industrial (I), and Automotive (T2)
temperature grades only.
Table 5-10. I/O Digital Receive Double Data Rate Switching Characteriscs
1,2
Parameter Interface Name Topology I/O
Type
STD
(MHz)
–1
(MHz)
STD
(Mbps)
–1
(Mbps)
Clock-to-Data
Condition
Input F
MAX
RX_DDR_G_A Rx DDR HSIO 335 345 670 690 From a global clock
source, aligned
GPIO 310 325 620 650
Input F
MAX
RX_DDR_R_A Rx DDR HSIO 250 250 500 500 From a regional
clock source, aligned
GPIO 250 250 500 500
Input F
MAX
RX_DDR_G_C Rx DDR HSIO 335 345 670 690 From a global clock
source, centered
GPIO 310 325 620 650
Input F
MAX
RX_DDR_R_C Rx DDR HSIO 250 250 500 500 From a regional
clock source,
centered
GPIO 250 250 500 500
Input F
MAX
2:1 RX_DDRX_B_G_A Rx DDR digital
mode
HSIO 350 350 700 700 From a HS_IO_CLK
clock source,
aligned, global fabric
clock
GPIO 300 310 600 620
Input F
MAX
4:1 RX_DDRX_B_G_A Rx DDR digital
mode
HSIO 350 350 700 700 From a HS_IO_CLK
clock source,
aligned, global fabric
clock
GPIO 300 310 600 620
Input F
MAX
3.5:1 RX_DDRX_B_G_FA Rx DDR digital
mode for
fractional
HSIO 350 350 700 700 From a HS_IO_CLK
clock source,
aligned, global fabric
clock, fractional
input
GPIO 320 320 640 640
Input F
MAX
2:1 RX_DDRX_B_G_C Rx DDR digital
mode
HSIO 350 350 700 700 From a HS_IO_CLK
clock source,
centered, global
fabric clock
GPIO 300 310 600 620
