AC Switching Characteriscs
Data Sheet
© 2024 Microchip Technology Inc. and its subsidiaries
DS00003831E - 33
...........continued
Standard STD –1 Unit
SSTL18II 800 800 Mbps
SSTL18I (dierential) 800 800 Mbps
SSTL18II (dierential) 800 800 Mbps
SSTL15I 800 1066 Mbps
SSTL15II 800 1066 Mbps
SSTL15I (dierential) 800 1066 Mbps
SSTL15II (dierential) 800 1066 Mbps
HSTL15I 900 900 Mbps
HSTL15II 900 900 Mbps
HSTL15I (dierential) 900 900 Mbps
HSTL15II (dierential) 900 900 Mbps
HSUL18I 400 400 Mbps
HSUL18II 400 400 Mbps
HSUL18I (dierential) 400 400 Mbps
HSUL18II (dierential) 400 400 Mbps
PCI 500 500 Mbps
LVTTL (20 mA) 500 500 Mbps
LVCMOS33 (20 mA) 500 500 Mbps
LVCMOS25 (16 mA) 500 500 Mbps
LVCMOS18 (12 mA) 500 500 Mbps
LVCMOS15 (10 mA) 500 500 Mbps
LVCMOS12 (8 mA) 250 300 Mbps
MIPIE25 1000 1000 Mbps
Note: LVDS25 conguration should be used when implementing SGMII transmitters.
5.1.5 Maximum PHY Rate for Memory Interface IP
The following tables describe the maximum PHY rate for memory interface IP.
–STD speed grade is oered for Extended Commercial (E), Industrial (I), Military (M), and Automotive
(T2) temperature grades.
–1 speed grade is oered for Extended Commercial (E), Industrial (I), and Automotive (T2)
temperature grades only.
Table 5-7. Maximum PHY Rate for Memory Interfaces IP for HSIO Banks
Memory Standard Gearing Ratio V
DDAUX
V
DDI
STD
(Mbps)
Min
STD
(Mbps)
Max
–1
(Mbps)
Min
–1
(Mbps)
Max
Fabric
Clock
STD
Min
(MHz)
Fabric
Clock
STD
Max
(MHz)
Fabric
Clock
–1
Min
(MHz)
Fabric
Clock
–1
Max
(MHz)
DDR4 8:1 1.8V 1.2V 800 1333 800 1600 100 167 100 200
DDR3 8:1 1.8V 1.5V 800 1067 800 1333 100 133 100 167
