Hi-Rel Standard
General Requirements
Product Specication
© 2025 Microchip Technology Inc. and its subsidiaries
DS00005882A - 4
2. General Requirements
2.1 Classicaon
All devices delivered to this specication are of hybrid technology conforming to Type 1, Class 2
of MIL-PRF-55310. Primarily developed as a Class S equivalent specication, options are imbedded
within it to also produce Class B, Engineering Model and Ruggedized COTS devices. Devices carry a
Class 2 ESDS classication per MIL-PRF-38534.
2.2 Item Idencaon
Unique model number series are utilized to identify device package congurations as listed in Table
6-1.
2.3 Absolute Maximum Rangs
Table 2-1. Absolute Maximum Rangs
Parameter Value
Supply Voltage Range (V
CC
= 3.3V or 5V)
Supply Voltage Range (V
CC
=
1.8V or 2.5V)
–0.5 Vdc to +7.0 Vdc
–0.3 Vdc to +4.8 Vdc
Storage Temperature Range (T
STG
) –65 °C to +125 °C
Junction Temperature (T
J
) [V
CC
= 3.3V or 5V]
Junction Temperature (T
J
) [V
CC
=
1.8V or 2.5V]
+175 °C
+150 °C
Lead Temperature (Soldering, 10 Seconds) +300 °C
Output Source/Sink Current ±50 mA
2.4 Design, Parts, Materials and Processes, Assembly, Inspecon and Test
2.4.1 Design
The ruggedized designs implemented for these devices are proven in military and space applications
under extreme environments. Designs utilize 4-point crystal mounting in compliment with
Established Reliability (MIL-ER) componentry. When specied, radiation lot acceptance testing up
to 300 krad(Si) (RHA level F) can be included without altering the device’s internal topography.
2.4.1.1 Design and Conguraon Stability
Barring changes to improve performance by reselecting passive chip component values to oset
component tolerances, there will not be fundamental changes to the design or assembly or parts,
materials, and processes after rst product delivery of that item without notication.
2.4.1.2 Environmental Integrity
Designs have passed the environmental qualication levels of MIL-PRF-55310. These designs have
also passed extended dynamic levels of at least:
a. Sine Vibration: MIL-STD-202, Method 204, Condition G (30g pk.)
b. Random Vibration: MIL-STD-202, Method 214, Condition II-J (43.92g rms, three- minute duration in
each of three mutually perpendicular directions)
c. Mechanical Shock: MIL-STD-202, Method 213, Condition F (1500g, 0.5 ms)
