Hi-Rel Standard
Ordering Informaon
Product Specication
© 2025 Microchip Technology Inc. and its subsidiaries
DS00005882A - 13
6. Ordering Informaon
6.1 Ordering Part Number
The ordering part number is made up of an alphanumeric series of 15 characters. Design-aected
product options, identied by the parenthetic letter on the Optional Parameters list (4.2. Optional
Design, Test, and Data Parameters), are included within the device part number.
The Part Number breakdown is described as:
Figure 6-1. Part Number Breakdown
1504 F 50M00000 B F
Model# (Table 6-1)
Input Voltage
A = +5.0V
B = +3.3V
C = +2.5V
D = +1.8V
Design Pedigree (Para 3.1)
E = 300 krad, Enhanced Element
Evaluation, Swept Quartz
R = 300 krad, Class K (Rev K)
Components, Swept Quartz
V = 300 krad, Class K (Rev K)
Components, Non-Swept
Quartz
D = Ruggedized COTS: Non-
Swept Quartz, Commercial
Grade Components
Frequency
Screening Option
Table 6-7 and Table 4-1
6.1.1 Model Number
The device model number is the four (4) digit number assigned to a corresponding package and
output combination per Table 6-1.
6.1.2 Design Pedigree
Class S variants correspond to either letter “E”, “F”, or “V” and are described in 4.2. Optional Design,
Test, and Data Parameters paragraph a. Ruggedized COTS, using commercial grade components,
corresponds to letter “D”.
6.1.3 Output Frequency
The nominal output frequency is expressed in the format as specied in MIL-PRF-55310 utilizing
eight (8) characters.
