Vega TP-3 Operating Manual Page 7
If the “RESISTIVE” pressure sender is selected
Sender:
Select what type of resistive pressure sender you are using. Select “VDO” for VDO / resistive senders, “USER” for a
custom sender.
Model:
Select which VDO pressure sender you are using. A selection between a VDO 2, 5 or 10 Bar can be selected.
If the “VOLTAGE” pressure sender is selected
Sender:
Select the type of voltage sender you are using. Select “UMA” for UMA senders, "0.5-4.5V" for voltage senders, or
“USER” for a custom voltage sender.
Model:
For UMA senders select the UMA model number.
If the “CURRENT” pressure sender is selected
Sender:
Select the type of current sender you are using. Select “4-20mA” for Rotax 912/914 4-20mA sender or “USER” for a
custom 4-20mA sender.
Pressure @ 4mA:
Enter the pressure specified at 4mA output.
Pressure @ 20mA:
Enter the pressure specified at 20mA output.
Menu options for all sender types
If the “USER" pressure sender is selected
Calibrate Sender:
If the sender type is set to “USER”, then use this menu option to calibrate your pressure sender. See section 4.2.3 for
more information.
Label:
Enter a label to suit your pressure channel so you can identify it easily.
Unit:
Select whether you want to display the pressure in Bar, psi or psi(0.1). The psi(0.1) is for low range pressure senders e.g.
UMA 7PSI.
Display Max:
Select the maximum pressure that you want the bargraph to show. This can give you increased display resolution.
Display Max:
Select the minimum pressure that you want the bargraph to show. This can give you increased display resolution.
