CONNECTIONS
From the 16-pin harness with stripped leads to the aftermarket radio:
• Connect the Red wire to the accessory wire.
Note: There will also be an accessory wire from the 8163 harness to connect as well.
• Tape off and disregard the following (14) wires, they will not be used in this application:
Blue/White, Brown, Gray, Gray/Black, Green, Green/Black, Orange/White, Purple,
Purple/Black, White, White/Black, Blue/Pink, Green/Purple, Light Green
From the 8163 harness to the aftermarket radio:
• Connect the Black wire to the ground wire.
• Connect the Yellow wire to the battery wire.
• Connect the Blue wire to the power antenna wire.
• Connect the Blue/White wire to the accessory wire.
• Connect the Red and White RCA jacks to the audio AUX-IN jacks from the aftermarket radio.
• Tape off and disregard the following (4) wires, they will not be used in this application:
White, White/Black, Gray, Gray/Black
• Use the appropriate amplifier bypass included with the kit to connect to the speakers,
following the instructions included with the amplifier bypass. Take note that there are
multiple speakers in the vehicle with varying impedance. An external amplifier(s) and either
active or passive crossovers will be required (not provided).
Continued on the next page
