99-7428
2
1.
Unclip and remove the trim panel above
the radio and climate controls. (Figure A)
2. Remove (1) Phillips screw under the
panel securing the center dash panel.
(Figure B)
3. Unclip and remove the center dash
panel including the radio and climate
controls. (Figure C)
4. Remove (10) Torx T-10 screws from
the climate control/radio trim panel to
remove it from the center dash panel.
5. Remove (4) Torx T-10 screws securing
the climate controls to the factory trim panel
.
Continue to kit preparation
Dash Disassembly Kit Preparation
1. Attach the climate controls to the
radio housing using the factory
hardware removed in the dash
disassembly. (Figure A)
2. Attach the radio housing to the
center dash panel using the
factory hardware removed in the
dash disassembly. (Figure B)
Continue to kit assembly
CLIMATE CONTROLS
REAR VIEW OF FACTORY TRIM PANEL
REAR VIEW OF FACTORY TRIM PANEL
REAR VIEW OF FACTORY TRIM PANEL
(Figure B)
(Figure A)
(Figure C)
(Figure D) (Figure E) (Figure B)
CLIMATE CONTROLS
(Figure A)
