REV. 4/29/22 INST99-6548
KIT ASSEMBLY
ISO DIN radio provision with pocket
4. Attach the (6) panel clips provided with
this kit onto the 99-6548 radio/climate
1. Secure the
pocket
to the
radio brackets
control trim panel. (Figure C)
using the (4) #8 x 3/8" Phillips screws
provided. (Figure A)
5. Locate the factory wiring harness and
antenna connector in the dash and
2. Remove the metal DIN sleeve and trim
complete all necessary connections to
ring from the aftermarket radio.
the radio. Metra recommends using the
3. Slide the radio into the bracket/pocket
proper mating adapter from Metra and/
assembly, and then secure it using the
or Axxess.
screws supplied with the radio.
6. Reconnect the negative battery terminal
(Figure B)
and test the aftermarket radio for proper
operation.
7. Secure the radio assembly to the dash
using the factory screws.
(Figure C)
8. Reassemble the dash in reverse order of
disassembly using the 99-6548 radio/
climate control trim panel to complete
the installation.
(Figure A)
(Figure B)
3
