• For all other radios: Connect the 3.5mm jack from the 6536 harness to the jack on
the aftermarket radio designated for an external steering wheel control interface.
Please refer to the aftermarket radio’s manual, if in doubt as to where the 3.5mm
jack connects.
4-pin harness with yellow RCA jacks:
• If retaining the factory backup camera to the touchscreen display is desired, connect
the Yellow RCA jack labeled “Rearview camera”, to the Yellow RCA jack from the
6536
harness
.
Note: If this method is chosen, the backup camera option must be enabled in the
Settings
screen
.
• Disregard the Yellow RCA jack labeled “AUX video”, it will not be used in this
application.
CONNECTIONS (CONT.)
3.5mm jack steering wheel control retention:
The 3.5mm jack is to be used to retain audio controls on the steering wheel.
•
For the radios listed below: Connect the
female 3.5mm connector with stripped leads
to the
male 3.5mm SWC jack from the 6536 harness.
Tape off and disregard any remaining wires.
•
Eclipse: Connect the steering wheel control wire, normally Brown, to the Brown/White
wire from the connector. Then connect the remaining steering wheel control wire,
normally Brown/White, to the Brown wire from the connector
.
•
Metra OE:
Connect the Gray steering wheel control wire (Key 1) to the Brown wire.
•
Kenwood or select JVC with a steering wheel control wire:
Connect the
Blue/Yellow
wire to the
Brown
wire.
Note:
If your Kenwood radio auto detects as a JVC, manually set the radio type to
Kenwood. See the instructions under changing radio type.
• XITE:
Connect the steering wheel control SWC-2 wire from the radio to the
Brown
wire.
•
Parrot Asteroid Smart or Tablet:
Connect the 3.5mm jack into the AX-SWC-PARROT
(sold separately), and then connect the 4-pin connector from the AX-SWC-PARROT into
the radio.
Note:
The radio must be updated to rev. 2.1.4 or higher software.
•
Universal “2 or 3 wire” radio:
Connect the steering wheel control wire, referred to as
Key-A or SWC-1, to the
Brown
wire from the connector. Then connect the remaining
steering wheel control wire, referred to as Key-B or SWC-2, to the
Brown/White
wire
from the connector. If the radio comes with a third wire for ground, disregard this wire
.
Note:
After the interface has been programmed to the vehicle, refer to the manual
provided with the radio for assigning the SWC buttons. Contact the radio manufacturer
for more information.
