5
REV. 11/16/23 INST99-6536
AXXESS INTERFACE INSTALLATION
INTERFACE FEATURES
• Designed for amplified and non-amplified models
• Provides accessory power (12-volt 10-amp)
• Retains R.A.P. (retained accessory power)
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains audio controls on the steering wheel
• Retains safety chimes
• Retains the factory backup camera
• Retains the factory AUX-IN jack
• Retains balance and fade (in non-amplified models only)
• USB Micro-B updatable
INTERFACE COMPONENTS
• Axxess interface (built into the touchscreen display)
• 6536 harness
• 16-pin harness with stripped leads
• 4-pin harness with yellow RCA jacks
• Hazard harness (LD-CHRYHAZ2)
• Female 3.5mm connector with stripped leads
TABLE OF CONTENTS
Connections
For Models
without
an Amplifier ............................................................................................6
For Models
with
an Amplifier. .................................................................................................7
3.5mm Jack Steering Wheel Control Retention ....................................................................8
Installation ....................................................................................................................................9
Programming ................................................................................................................................9
Final Assembly ..............................................................................................................................9
Touchscreen Display Operation ............................................................................................. 10-11
Steering Wheel Control Settings ...........................................................................................12-13
Troubleshooting.......................................................................................................................... 14
TOOLS REQUIRED
• Wire cutter
• Crimp tool and connectors (example: butt-connectors, bell caps, etc.)
or
• Solder gun, solder, and heat shrink
• Tape
• Zip-ties
• Small flat-blade screwdriver
