Je bekijkt pagina 6 van 40
386.257.1187
|
MetraOnline.com
6
AXXESS INTERFACE INSTALLATION
INTERFACE FEATURES
INTERFACE COMPONENTS
• Axxess interface (built into kit)
• Car side harness (LD-TSCREEN-FD3)
• HVAC interface
• HVAC interface harness (LD-FDHVAC)
• 4-pin flat to 4-pin stacked harness (packaged with the HVAC harness)
• 16-pin harness with stripped leads (LD-2NAVAMPL)
• 14-pin harness with stripped leads and a two-pin plug (LD-FD-AUX)
• 54-pin backup camera harness with a two pin plug (LD-FD54CAM)
• Female 3.5 with stripped leads (LD-SWC-F3.5)
TOOLS REQUIRED
• Crimping tool and connectors, or solder gun, solder, and heat shrink
• Tape • Wire cutter • Zip ties
• Provides accessory power (12-volt 10-amp)
• Retains R.A.P. (retained accessory power)
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains audio controls on the steering wheel
• Allows the override of the STOP/START engine feature
• The factory STOP/START button can resume the STOP/START feature
• Retains the factory backup camera
• Factory B&O amplified sound systems require and additional interface sold separately.
Part # AX-A2B-FD1.
• Retains balance and fade (excluding Sony)
• Micro-B USB updatable
TABLE OF CONTENTS
Connections
For models
without
a Sony or B&O amplifier .......................................................................... 7
For models
with
a Sony amplifier ............................................................................................ 8
3.5mm jack - steering wheel control retention ......................................................................9
Backup camera harness ............................................................................................................ 9
Installation ...................................................................................................................................10
Programming ................................................................................................................................ 11
Configuration Menu ................................................................................................................12-14
Attention! This interface will work with models that are either Sony amplified, or non-
amplified. Please follow the instructions carefully for your model vehicle. Failure to do
so will result in either no sound, or low sound. If you are unsure if your vehicle is factory
amplified or not, please contact your local dealership.
