REV. 1/18/23 INST99-5863HG

AXXESS INTERFACE INSTALLATION

• Crimping tool and connectors, or solder gun, solder, and heat shrink

• Tape • Wire cutter • Zip-ties

TOOLS REQUIRED

INTERFACE FEATURES

INTERFACE COMPONENTS

• Car side harness (LD-TSCREEN-FD3)

• 16-pin harness with stripped leads (LD-2NAVAMPL)

• Console USB retention cable & knockout (BP-FD-USB3)

• Airbag/hazard harness (LD-EXPL-DZ)

• Airbag adaptor harness (LD-AIRADAPT)

• Female 3.5 with stripped leads (LD-SWC-F3.5)

• Camera retention harness (LD-FD54CAM)

• Antenna adapter: 40-EU10

• Retains retained accessory power (12-volt 10-amp)

• Provides NAV outputs (parking brake, reverse, speed sense)

• Retains audio controls on the steering wheel

• Retains the factory backup camera

• Includes USB replacement harness

• Retains balance and fade

• USB Micro-B updatable

Connections ...........................................................................................................................................6-7

Installation ...............................................................................................................................................8

Programming ...........................................................................................................................................8

Conﬁguration menu ............................................................................................................................9-11

TABLE OF CONTENTS
