CONNECTIONS (CONT.)
From the CAR SIDE HARNESS (LD-TSCREEN-FD3) to the aftermarket radio, connect as indicated:
• Black wire to the ground wire. Also connect black from the 54CAM harness.
• Yellow wire to the battery wire.
• Green wire to the left rear (+) speaker output.
• Green/Black wire to the left rear (-) speaker output.
• Purple wire to the right rear (+) speaker output.
• Purple/Black wire to the right rear (-) output.
• Tape off and disregard the following (1) wire, it will not be used in this application: Blue
• Disregard the Red and White RCA jacks labeled “FROM 3.5”
• Disregard the Red and White RCA jacks labeled “RSE/SYNC
®
/SAT”, they will not be used in
this application.
Continue to 3.5mm jack - steering wheel control retention
3.5mm jack - steering wheel control retention:
From the 3.5mm jack to the aftermarket radio:
• Parrot: Connect the AX-SWC-PARROT (sold separately) to the 3.5mm jack, then to the radio.
• For the radios listed below: Connect the 3.5mm adapter to the 3.5mm jack.
• Eclipse: Brown - Brown/White / Brown/White - Brown
• Kenwood / JVC (with SWC wire): Blue/Yellow - Brown
• Metra OE: Key 1 (Gray) - Brown
• Universal “2 or 3 wire” radio: Key-A or SWC-1 - Brown / Key-B or SWC-2 - Brown/White
Note: After programming, assign SWC buttons within menu.
• XITE: SWC-2 - Brown
• For all other radios: Connect the 3.5mm jack to the radio.
